High thermal insulation materia LED lighting circuit boards

High thermal insulation materia LED lighting circuit boards

Payment Type: L/C,T/T,D/P,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order: 1 Piece/Pieces
Delivery Time: 8 Days

Contact Now Add to Basket

Basic Info

    Model No.: CW-016

    Structure: Metal Base Rigid PCB

    Flame Retardant Properties: V0

    Base Material: Aluminum

    Insulation Materials: Metal Composite Materials

Additional Info

    Transportation: Ocean,Land,Air

    Place of Origin:  China

    Supply Ability: 10000sqm/month

    Certificate: ISO9001, ISO14001, UL, IATF16949

Product Description

The heat dissipation problem of LEDs is the biggest headache for LED manufacturers, but aluminum substrates can be used. Because aluminum has high thermal conductivity and good heat dissipation, it can effectively extract internal heat. The aluminum substrate is a unique metal-based copper clad laminate with good thermal conductivity, electrical insulation properties and machinability. The PCB should also be placed close to the aluminum base as much as possible to reduce the thermal resistance generated by the potting compound.

The aluminum-based copper clad laminate is a metal circuit board material composed of a copper foil, a thermally conductive insulating layer and a metal substrate, and its structure is divided into three layers:
Circuit layer: equivalent to ordinary copper clad laminate board, line copper foil thickness loz to 10oz.
Insulation layer: The insulation is a low thermal resistance thermal insulation material.
Base Layer: It is a metal substrate, usually aluminum or copper. Aluminum-based copper clad laminates and conventional epoxy glass cloth laminates.


certification logo

Specifications:


Material: Aluminium

Layer: 1L

Copper thickness: 1OZ

Board thickness: 1.0mm

Surface Finishing: HASL-LF

Solder mask color: White

Silkscreen color: Black

Thermal Conductivity: 1.0W/M.K

Led Light
