5G signal printed circuit boards

Payment Type:
L/C,T/T,D/P,Money Gram,Western Union
Min. Order:
1 Piece/Pieces
Delivery Time:
8 Days
  • Product Description
Product Attributes

Model No.CW-125

StructureDouble-Sided Rigid PCB


ApplicationConsumer Electronics

Flame Retardant PropertiesV0

Supply Ability & Additional Informations


Place of Origin China

Supply Ability10000sqm/month

CertificateISO9001, ISO14001, UL, IATF16949

Payment TypeL/C,T/T,D/P,Money Gram,Western Union


Delivery Time8 Days

The antenna frame of a 5G base station needs to use a PCB as a connection. Compared with the PCB of the 4G era, the PCB used by 5G will be upgraded in many aspects, resulting in a significant increase in usage and value.
The first is that the area and number of layers of the PCB will be greatly improved. At present, the antenna array used by 4G generally does not exceed eight, and the antenna array of 5G will reach 192, forming a Massive MIMO array antenna. 4G is a separate PCB for each antenna array, and 5G is equipped with a PCB for the entire PCB to connect, using a large increase in PCB area. At the same time, due to the large increase in communication channels, the PCB used needs to be more complicated, and it needs to rise from the dual panel of the 4G era to the 12-layer board of the 5G era.
Secondly, the PCB material used in the PCB needs to use high-frequency high-speed boards, which brings about a significant increase in the value.

certification logo


Material: FR4

Layer: 2L

Copper thickness: 1OZ

Board thickness: 2.0mm

Surface Finishing: Immersion gold

Solder mask color: Green

Silkscreen color: White

Describe: 5G

2 0mm 1oz 2l Enig 5g2 0mm 1oz 2l Enig 5g Signal________________________________________________________________________________________________________________________________________________________

Printed circuit boards abbreviation as PCB. A conductive pattern which is formed on a dielectric material in a predetermined design to form a printed circuit, a printed component, or a combination of the two is generally referred to as a printed circuit. And a conductive pattern that provides electrical connection between components on an insulating substrate, called printed circuits.

PCB characteristics
● High density. For decades, the high density of printed boards has grown with the increased integration of integrated circuits and advances in mounting technology.
● High reliability. Through a series of inspections, tests and aging tests, the PCB can be reliably operated for a long period of time (usually 20 years).
● Designability. For the various performances of PCB (electrical, physical, chemical, mechanical, etc.), the design of printed boards can be realized through design standardization and standardization, with short time and high efficiency.
● Productivity. With modern management, it can carry out standardization, scale (quantity), automation and other production to ensure product quality consistency.
● Testability. Established relatively complete test methods, test standards, various test equipment and instruments to detect and identify PCB product qualification and service life.

● Assemblyability. PCB products not only facilitate the standardized assembly of various components, but also can be automated, large-scale mass production. At the same time, the PCB and various component assembly components can be assembled to form larger components and systems up to the complete machine.

● Maintainability. Since PCB products and various component assembly components are produced in a standardized design and scale, these components are also standardized. Therefore, once the system fails, it can be replaced quickly, conveniently and flexibly, and the system can be quickly restored. Of course, you can say more about it. Such as miniaturization and weight reduction of the system, high-speed signal transmission, etc.
